Highly sensitive thermal sensor
Telos thermal imagers use an extremely sensitive thermal sensor with NETD below 18 mK, delivering top-tier thermal image quality and precise object recognition even in the most challenging weather conditions.
Pulsar Image Boost technology
Thanks to Pulsar Image Boost technology, Telos thermal imagers provide premium image quality with a high level of detail, clarity, and contrast.
Lens ring control
Telos series thermal imagers are easy to adjust using the focus and zoom ring mounted directly on the lens, allowing fast and intuitive operation.
Replaceable battery with fast wireless charging support
The new quick-replace LPS 7i lithium-ion battery delivers over 8 hours of operation and is compatible with the Power Delivery fast-charging protocol.
Ergonomic housing
The rubber-coated housing ensures a secure grip in both dry and rainy conditions. It is highly resistant to wear, temperature extremes, dust, and moisture, and protects the device from drops. The housing is easy to clean and retains its appearance over long-term use. The Telos thermal imager is equally suitable for right- and left-handed users.
Detection range
A standard 1.8-meter-tall object can be detected at distances of up to 1,800 meters.
Specifications
Model: Pulsar Telos XP50
Sensor resolution: 640×480 px @ 17 µm (NETD <18 mK)
Lens: F50 / 1.0
Magnification: 2.5–10× (4× digital zoom)
Field of view (H×V): 12.4×9.3° / 21.8×16.3 m @ 100 m
Detection range: 1800 m
Pixel size: 17 µm
Thermal sensitivity (NETD): <18 mK
Frame rate: 50 Hz
Eye relief: 14 mm
Display:
Type: AMOLED HD
Resolution: 1024×768 px
Video / photo format: .mp4 / .jpg
Internal memory: 64 GB
Environmental protection:
IP rating (IEC 60529): IPX7 (water resistant)
Operating temperature: −25 to +40 °C
Connectivity:
Wi-Fi: Yes
Mobile app: Stream Vision 2
Power supply:
Output voltage: 3.0–4.2 V
Battery: LPS 7i Li-Ion
Capacity: 6400 mAh
Battery life (at 22 °C): up to 8.5 h
External power supply: 5 V / 9 V (USB-C Power Delivery)
Mounting: 1/4″
Dimensions: 238 × 72 × 90 mm
