Quick Installation and Removal
The FD1 night vision mount features a quick-release adapter that allows the device to be easily and quickly attached to or detached from an optical riflescope. This is especially useful when lighting conditions change — switching from a standard optic to night vision takes only a few seconds.
Three-in-One
The PARD FD1 LRF night vision device is a versatile solution that combines three functions in one unit. It can be used as a clip-on scope, as a digital night vision monocular for observation, and as a digital riflescope for precise shooting. This means a single device allows both observation in darkness and quick preparation for a shot without additional equipment. An excellent choice for hunters who value versatility and convenience.
Removable and Rechargeable Battery
The device uses a 18650 lithium-ion battery with an operating time of up to 8 hours, providing reliable power throughout the night.
Compact and Lightweight
The PARD FD1 LRF is an extremely lightweight and compact night vision device, weighing only 328 g. Its small size and low weight make it a reliable hunting companion that is easy to carry, operate, and quickly mount onto optics even in demanding conditions.
Built-in Laser Rangefinder
The integrated LRF (laser rangefinder) module allows accurate distance measurement up to 1000 meters, enabling fast and precise distance calculation to the observed target.
Ballistic Calculation
The PARD FD1 LRF also functions as a ballistic calculator. The device supports five different ballistic profiles, includes an integrated rangefinder, and provides real-time data for accurate shooting decisions. This ensures fast and precise aiming in any conditions.
OLED Display and Clear Image
The FD1 LRF night vision device is equipped with a high-resolution 1440 × 1080 OLED display, providing excellent image clarity and detail. This allows clear identification of targets even in challenging conditions.
The PARD FD1 LRF also features an advanced CMOS image sensor with a resolution of 1920 × 1080 and light sensitivity down to 0.001 lux. This enables the device to capture clear and detailed images even in extremely low-light conditions, ensuring reliable performance at night or at dusk. PARD’s proprietary VLEA image enhancement technology significantly improves image clarity, reduces noise, and enhances overall image quality.
IP67 Protection
Be prepared for any environmental challenge — dust, rain, snow, or freezing temperatures. This device ensures reliable operation even in extreme weather and harsh conditions. IP67 protection means the device is completely dust-tight and can withstand immersion in water up to 1 meter for up to 30 minutes.
Picture-in-Picture (PIP) Mode
When the Picture-in-Picture function is enabled, a 2× magnified area appears at the top of the display, allowing faster and more precise target identification while maintaining a full field of view. This ensures more effective target tracking and quicker response in complex situations.
Recoil-Activated Recording
The device automatically starts video recording as soon as it detects recoil, allowing you to review the shot afterward.
Specifications
Sensor:
- Type: CMOS
- Resolution: 1920 × 1080 pixels
- Pixel size: 2.9 µm
- Frame rate: Color – 60 Hz, Black & White – 30 Hz
- Image processing engine: PARD VLEA
Optics
- Application: Clip-on (front mounting)
- Objective lens diameter: 30 mm
- Optical magnification: 1×
- Digital zoom: None
- Field of view: Horizontal 7.9°, Vertical 5.9°, Diagonal 9.9°
- Eye relief: None
- Diopter adjustment: None
Display:
- Type: OLED
- Resolution: 1440 × 1080 pixels
- Reticle styles: 6 options
- Image modes: Color / Monochrome
Photo / Video
- Photo resolution: 2592 × 1944 pixels
- Photo format: JPG
- Video format: MP4
- Memory: TF card up to 128 GB
Main Functions
- Mounting type: Clip-on
- Laser rangefinder (LRF) detection range: up to 1000 m
- Ballistic calculator: No
- Picture-in-Picture (PIP): No
- Automatic recording: Yes
- Loop recording: Yes
- Microphone: Yes
- Infrared (IR) wavelengths: 850 / 940 nm
- IR illumination levels: 3 levels
Connectivity:
- USB: Type-C
- Wi-Fi: Yes
- Supported apps: PardVision
Power:
- Battery type: Lithium-ion 18650
- Output voltage: 3.7 V
- Maximum operating time: up to 8 hours
- External power supply: USB Type-C
Environmental & Durability:
- Protection rating: IP67 (dustproof and waterproof)
- Operating temperature: −20 °C to +50 °C (−4 °F to 122 °F)
- Recoil resistance: 6000 J
Housing:
- Material: Aluminum alloy
