Exceptional image quality
The Nocpix MATE ULTRA optical viewfinder attachment offers exceptional image quality with 1280×1024 resolution and a 60 mm lens. The NETD ≤15 mK thermal sensitivity ensures sharp and detailed images, even when capturing small temperature changes. The ultra-high 60 Hz frame rate guarantees smooth image refresh and allows you to clearly observe fast-moving objects without image lag. The Nocpix MATE ULTRA attachment is compatible with optics with up to 16x zoom.
60mm Large Lens
The large-aperture 60mm lens pulls in more thermal energy for unmatched long-range detection and striking image clarity—giving you the power to spot and identify game with absolute confidence, even in the toughest environments.
Advanced image algorithms
Powered by dual algorithms—an advanced image engine and intelligent R+ technology that adjusts to your scope’s magnification—MATE ULTRA keeps your image sharp and detailed, even in fog, drizzle, or low light. Clear visuals, no matter the conditions.
Wide Field of View
Compare that with smaller fields of view, and you can see that MATE ULTRA allows you to capture more of your surroundings without even moving an inch. Whether scanning open terrain or detecting movement through thick brush, you remain aware, always in control.
60Hz Frame Rate
With a 60 Hz refresh rate, shutterless imaging, and a powerful 4 TOPS processor, the MATE ULTRA delivers fluid, uninterrupted visuals—free from shutter pauses and motion blur. Fast-moving targets stay sharp and clear, ensuring split-second clarity when timing is critical.
Restore what the naked eye sees
Nocpix MATE uses a 35 mm eyepiece with ultra-low less than 0.5% distortion to maintain image accuracy—even at up to 16× magnification. This ensures a stable point of impact and consistent visual alignment, so every shot lands exactly where it’s aimed.
Shutterless Imaging
The shutterless technology ensures that there’s no need for manual calibration, allowing for a smooth and fluid image at all times. Even fast-moving targets remain sharp, with every detail captured instantly.
Magic Zoom
With Magic Zoom, as you zoom in or out, the thermal image and interface adjust automatically, in real time. Without it Magic Zoom it can blur or misalign, MATE ULTRA keeps everything sharp and aligned at any magnification. AI ensures a fast, smooth view that stays locked on target — natural, effortless, and smart.
1 MOA Professional-Grade Accuracy
Excellent Repeated Disassembly Fault Tolerance
NOCPIX MATE is designed to be swapped easily between different rifles. No tedious re-zeroing, no wasted time or ammunition. Mount it, lock it, and your point of impact stays consistent — even after repeated mounting and disassembly. That’s factory-calibrated precision with fault tolerance you can count on, right out of the box.
Build-in 1200m LRF & Next-gen Ballistic Calculation Solution
NOCPIX MATE features a built-in 1200-meter laser rangefinder. Nocpix has developed a next-generation ballistic calculation solution, compared to the previous version, It can directly CORRECT the final image, make your aiming point equales to real target based on the balllistic calculation. This empowers hunters to make confident and informed shots.
Stronger. Lighter two-piece magnesium alloy body
The body is crafted from a two-piece magnesium alloy, which is lighter, stronger, and tougher than traditional housings. This design minimizes vibration, maximizes stability, and ensures consistent accuracy season after season. Recoil-tested up to 7000 joules, the MATE ULTRA withstands the harshest conditions and keeps your shots exactly where they need to be.
Standard 18650 Battery
Nocpix MATE runs on widely available 18650 rechargeable batteries, making replacements simple—no special cells required. With over 4 hours of runtime on a single charge, it’s built to go the distance on extended hunts.
More Functions
Specifications
| Model | Nocpix MATE H38R |
| Resolution | 640 × 512 |
| Pixel size, μm | 12μ |
| Thermal sensitivity NETD, mK | ≤15 |
| Frame rate, Hz | 60 |
| Lens, mm | 38F1.0 |
| Field of view, (HxV),° | 11.6 × 8.7 |
| Field of view on the horizon, (HxV),° m@100m | 20.5 × 15.4 |
| Detection distance | 1950m. |
| Ekranas | AMOLED |
| Screen resolution | 1920 × 1080 |
| Battery | replaceable 18650 battery x3 |
| Max. operating time, (t=22°C) hours | 4 hours |
| Sound recording | Yes |
| Gallery | Yes |
| N-way | Yes |
| Remote control | Yes |
| MAGIC ZOOM | Yes |
| Weight, g (with battery) | 457g. |
| Size, mm | 115x85x76 |
| Ballistic calculation | Yes |
| Maximum rangefinder measurement distance (m) | 1200 |
| interface | M52 |
