Bright 1920×1080 (Full HD) display
The bright 1920×1080 (Full HD) display ensures that every detail is shown clearly, fully immersing the user in the “thermal world.”
Higher thermal sensitivity (NETD <15mK)
The HIKMICRO THUNDER 3.0 thermal camera is equipped with a highly sensitive thermal sensor (NETD <15mK), capable of detecting even the smallest temperature differences. This means that even in challenging conditions you will see a clear, detailed image — the animal’s fur, sex, age, and even antlers.
Smooth monitoring with HIKMICRO’s interference-free calibration system (HSIS)
HIKMICRO’s innovative HSIS Thermal Image Calibration System allows smooth, interruption-free viewing and eliminates the need for manual calibration. This advanced feature provides a stable image without distractions, keeping hunters focused during the most important moments.
Clear visibility even with 15x magnification day optics
When used with high-magnification day optics (up to 15x), the HIKMICRO THUNDER 3.0 thermal attachment delivers a clear image and precise control, ensuring accurate shots at long distances.
Virtual reticle for better shot assessment
The virtual reticle visible in HIKMICRO Thunder 3.0 recordings helps hunters better evaluate and analyze each shot.
Specifications
| Resolution | 384 × 288 |
| Frame rate | 50Hz |
| Pixel density | 12 μm |
| IR beam wavelength | 8 μm to 14 μm |
| Lens (focal length) | 35mm, F1.0 |
| NETD (sensor sensitivity) | Less than 15 mK (@25 °C, F# = 1.0) |
| Detection distance | 1800 |
| Focus type | Focus wheel |
| Min. focusing distance | 10 years |
| Zooming | 1x |
| Field of View (H × V), Degrees / m @100m | 7.5° × 5.7°/13.2 m × 9.9 m |
| Zooming possible with daylight optics | 1-12x |
| Screen | 1920 × 1080, 0.49 inch, OLED |
| Image palettes | Black – Hot, White – Hot, Red – Hot, Fusion, Red Monochrome, Green Monochrome |
| Aperture limiter image size (Exit Pupil) | 25 mm |
| Optimal distance of the observing eye from the lens (Eye Relief) | 20 mm |
| Setting the color tone | Cold, warm |
| Video recording/photo shooting | There is |
| Shot profiles | 5 |
| Battery type | Replaceable and rechargeable Li-ion battery (2 pcs. included) |
| Battery life | ≥6h (25 °C, with Hotspot function disabled) |
| Power supply via Type-C connector | 5 VDC, 2 A Supports external power supply. Supports on-device battery charging. |
| Environmental protection class | IP67 |
| Size | 143.4 mm × 67.5 mm × 72.9 mm |
| Weight | 460g with battery |
| Operating temperature | From -30°C to + 55°C |
| Height from center axis | 32mm |
