Ergonomic design and easy tracking
The dual eyepiece design reduces eye fatigue during prolonged viewing. The adjustable interpupillary distance (60-70 mm) allows you to adapt the device to different user needs. Ergonomic, raised buttons ensure easy operation even in complete darkness, making the device intuitive and comfortable to use.
Built-in rangefinder
The integrated laser rangefinder measures distances up to 1500 meters.
High definition image
The 640×480 thermal sensor delivers thermal image detail, allowing you to clearly see fine details and distinguish objects from their surroundings. The 50Hz frame rate provides smooth, stutter-free images, so you can effectively track even fast-moving objects.
Full color OLED display
The 1024 × 768 resolution color OLED display provides high contrast and sharp details, allowing you to recognize objects even in poor weather conditions.
PIP: Picture-in-picture function
A small screen with a magnified view appears at the top of the screen. This is a great way to zoom in on an object while maintaining a wider field of view.
Smooth zoom for flexible searching
Pressing the up or down button harder will zoom in or out, allowing you to adjust your field of view. This feature allows you to quickly zoom in to see fine details, or zoom out to see a larger area.
Color palette
Video modes
With the touch of a button, you can quickly switch between Enhance, Highlight, and Natural modes. These modes automatically adjust the image to different environmental conditions. Enhance and Highlight modes help reduce image noise and make the subject more visible in poor weather conditions.
Photo and video recording
Guide TN650 with photo and video recording function. The WiFi connection function allows you to remotely control the device, broadcast live images and share photos or videos via a mobile app.
Protection class IP66
The Guide TN650 thermal imaging binoculars are resistant to strong water jets, dust and shocks, so you can be sure that the binoculars will work reliably even in the most difficult situations. A wide operating temperature range from -30°C to +55°C ensures that the binoculars will not lose functionality in either snowy winters or hot summers. In addition, the TN650 complies with UN38.3 battery certification, RoHS, CE and FCC standards, which guarantee not only the quality of the device, but also its safety and durability.
Specifications
Thermal sensor: 640×480 12μm
Thermal sensitivity NETD: 30mK
Frame rate: 50Hz
Objective lens: 50mm, F1.2
Field of view FOV: 8.78°×6.59°
Field of view FOV m@100m: 15×12
Zoom: 2.8x~22.4x
Detection distance: 2600m
Display: AMOLED 1024×768
Color palette: Black Hot, White Hot, Adjustable Red Hot, Iron Red, Blue Hot, Green Hot
Diopter adjustment: -6 to +6
Interpupillary distance adjustment: 60 mm – 70 mm
Zoom: 13.8x
Rangefinder: Yes
Rangefinder measurement distance: 1500m
WIFI: 2.4G
Interface: USB-C; Micro HDMI
Other: GPS, Compass, Gyroscope, Bluetooth
Photo/Video: Yes
Memory: 16GB
Battery: 2 replaceable 18650 batteries
Operating time: 6 hours
Protection class: IP66
Size: 162×146×70
